NGK's Gold Palladium Plugs Feature a Fine Wire Gold Palladium Center Electrode for Improved Ignitability, Increased Durability and Enhanced Anti-Fouling Capabilities.
- Trivalent Metal Plating Provides Superior Anti-Corrosion and Anti-Seizing Properties
- Corrugated Ribs Prevent Flashover
- Pure Alumina Silicate Ceramic Insulator, Provides Superior Strength and Better Heat Transfer
- Copper Core Aids in Heat Removal
- Triple Seals Prevent Leakage
- Sold individually
Features
- Fine Wire Center Electrode
- Enhanced Anti-Fouling Capabilities
- Gold Palladium Increases Durability
Shell
- Thread Size: 14mm
- Thread Pitch: 1.25mm
- Seat Type: Gasket
- Resistor: No
- Reach: 19mm (3/4")
- Hex Size: 13/16" (21mm)
- Terminal Type: Removable Nut
- Overall Height: ISO
- Gap:. 026" (0.65mm)
Center Electrode
- Material: Gold-Palladium
- Type: Fine Wire
- Size: 1.0mm
- Projection: Non-Projected
Ground Electrode
- Material: Nickel
- Type: Standard
- Quantity: 1
Specifications
- Torque Specs: Cast Iron: 18-25.3 lb. ft. Aluminum: 18-21.6 lb. ft.
- Brand: NGK
- Heat Range: 10
Note: Image for reference only, actual product may vary.
| Stock # | B10EGV |
|---|---|
| Brand | NGK |
| Vend | PR |
| In Stock Message | Special Order - Requires 3-5 business days prior to shipment. |
